Solar Duty Transformer
SE's solar duty transformers are designed for use in the renewable energy market and are rated for bidirectional use to allow power to flow to or from the electrical grid. These units are specifically designed for situations where voltage adjustments are required between the PV array, end user and the utility. SE's transformer solutions for renewable energy applications help make solar power generation a reality in utility and commercial applications.
Technical Specification
| Applicable Standards | IS, IEC, ANSI, JIS, etc. |
| Cooling | ONAN, OA |
| Insulating Fluid | Mineral Oil to specification |
| Frequency | 50 Hz, 60 Hz |
| Polarity | As specified |
| Primary voltage | 11 KV Class |
| Secondary Voltage | 120, 120/240, 210-105, 250, 240/480 V |
| Winding material | Copper / Aluminium |
| Taping range | ± 5% in steps of 2.5% (Other tapings as required) |
| Impedance | In line with applicable standards. |
